Thin Reports, Report Level Measures vs Data Model Measures

Thin Reports, Report Level Measures vs Data Model Measures

The previous post explained what Thin reports are, why we should care and how we can create them. This post focuses on a more specific topic, Report Level Measures. We discuss what report-level measures are, when and why we need them and how we create them.

If you are not sure what Thin Report means, I suggest you check out my previous blog post before reading this one.

What are report level measures?

Report level measures are the measures created by the report writers within a Thin Report. Hence, the report level measures are available within the hosting Thin Report only which means the report level measures are not written back to the underlying dataset and hence they are not available to any other reports.

Why and when do we need report level measures?

It is a common situation in real-world scenarios when the business requires a report urgently, but the nuts and bolts of the report are not being created on the underlying dataset yet. For instance, the business requires to present a report to the board showing year-to-date sales analysis but the year-to-date sales measure hasn’t been created in the dataset yet. The business analyst approaches the Power BI developers to add the measure, but they are under the pump to deliver some other functionalities which adding a new measure is not even in their project delivery plan. It is perhaps too late if we wait for the developers to plan for creating the required measure, go through the release process, and make it available for us in the dataset. Here is when the report level measures come to the rescue. We can simply create the missing measure in the Thin Report itself, where we can later share it with the developers to implement it as a dataset measure.

Continue reading “Thin Reports, Report Level Measures vs Data Model Measures”

Thin Reports, What Are They, Why Should I Care and How Can I Create Them?

Thin Reports in Power BI

Shared Datasets have been around for quite a while now. In June 2019, Microsoft announced a new feature called Shared and Certified Datasets with the mindset of supporting enterprise-grade BI within the Power BI ecosystem. In essence, the shared dataset feature allows organisations to have a single source of truth across the organisation serving many reports.

A Thin Report is a report that connects to an existing dataset on Power BI Service using the Connect Live connectivity mode. So, we basically have multiple reports connected to a single dataset. Now that we know what a thin report is, let’s see why it is best practice to follow this approach.

Prior to the Shared and Certified Datasets announcement, we used to create separate reports in Power BI Desktop and publish those reports into Power BI Service. This approach had many disadvantages, such as:

  • Having many disparate islands of data instead of a single source of truth.
  • Consuming more storage on Power BI Service by having repetitive table across many datasets
  • Reducing collaboration between data modellers and report creators (contributors) as Power BI Desktop is not a multi-user application.
  • The reports were strictly connected to the underlying dataset so it is so hard, if not totally impossible, to decouple a report from a dataset and connect it to a different dataset. This was pretty restrictive for the developers to follow the Dev/Test/Prod approach.
  • If we had a fairly large report with many pages, say more than 20 pages, then again, it was almost impossible to break the report down into some smaller and more business-centric reports.
  • Putting too much load on the data sources connected to many disparate datasets. The situation gets even worst when we schedule multiple refreshes a day. In some cases the data refresh process put exclusive locks on the the source system that can potentially cause many issues down the road.
  • Having many datasets and reports made it harder and more expensive to maintain the solution.

In my previous blog, I explained the different components of a Business Intelligence solution and how they map to the Power BI ecosystem. In that post, I mentioned that the Power BI Service Datasets map to a Semantic Layer in a Business Intelligence solution. So, when we create a Power BI report with Power BI Desktop and publish the report to the Power BI Service, we create a semantic layer with a report connected to it altogether. By creating many disparate reports in Power BI Desktop and publishing them to the Power BI Service, we are indeed creating many semantic layers with many repeated tables on top of our data which does not make much sense.

On the other hand, having some shared datasets with many connected thin reports makes a lot of sense. This approach covers all the disadvantages of the previous development method; in addition, it decreases the confusion for report writers around the datasets they are connecting to, it helps with storage management in Power BI Service, and it is easier to comply with security and privacy concerns.

Continue reading “Thin Reports, What Are They, Why Should I Care and How Can I Create Them?”

Business Intelligence Components and How They Relate to Power BI

Business Intelligence Components and How They Relate to Power BI

When I decided to write this blog post, I thought it would be a good idea to learn a bit about the history of Business Intelligence. I searched on the internet, and I found this page on Wikipedia. The term Business Intelligence as we know it today was coined by an IBM computer science researcher, Hans Peter Luhn, in 1958, who wrote a paper in the IBM Systems journal titled A Business Intelligence System as a specific process in data science. In the Objectives and principles section of his paper, Luhn defines the business as “a collection of activities carried on for whatever purpose, be it science, technology, commerce, industry, law, government, defense, et cetera.” and an intelligence system as “the communication facility serving the conduct of a business (in the broad sense)”. Then he refers to Webster’s dictionary’s definition of the word Intelligence as the ability to apprehend the interrelationships of presented facts in such a way as to guide action towards a desired goal”.

It is fascinating to see how a fantastic idea in the past sets a concrete future that can help us have a better life. Isn’t it precisely what we do in our daily BI processes as Luhn described of a Business Intelligence System for the first time? How cool is that?

When we talk about the term BI today, we refer to a specific and scientific set of processes of transforming the raw data into valuable and understandable information for various business sectors (such as sales, inventory, law, etc…). These processes will help businesses to make data-driven decisions based on the existing hidden facts in the data.

Like everything else, the BI processes improved a lot during its life. I will try to make some sensible links between today’s BI Components and Power BI in this post.

Generic Components of Business Intelligence Solutions

Generally speaking, a BI solution contains various components and tools that may vary in different solutions depending on the business requirements, data culture and the organisation’s maturity in analytics. But the processes are very similar to the following:

  • We usually have multiple source systems with different technologies containing the raw data, such as SQL Server, Excel, JSON, Parquet files etc…
  • We integrate the raw data into a central repository to reduce the risk of making any interruptions to the source systems by constantly connecting to them. We usually load the data from the data sources into the central repository.
  • We transform the data to optimise it for reporting and analytical purposes, and we load it into another storage. We aim to keep the historical data in this storage.
  • We pre-aggregate the data into certain levels based on the business requirements and load the data into another storage. We usually do not keep the whole historical data in this storage; instead, we only keep the data required to be analysed or reported.
  • We create reports and dashboards to turn the data into useful information

With the above processes in mind, a BI solution consists of the following components:

  • Data Sources
  • Staging
  • Data Warehouse/Data Mart(s)
  • Extract, Transform and Load (ETL)
  • Semantic Layer
  • Data Visualisation

Data Sources

One of the main goals of running a BI project is to enable organisations to make data-driven decisions. An organisation might have multiple departments using various tools to collect the relevant data every day, such as sales, inventory, marketing, finance, health and safety etc.

The data generated by the business tools are stored somewhere using different technologies. A sales system might store the data in an Oracle database, while the finance system stores the data in a SQL Server database in the cloud. The finance team also generate some data stored in Excel files.

The data generated by different systems are the source for a BI solution.

Staging

We usually have multiple data sources contributing to the data analysis in real-world scenarios. To be able to analyse all the data sources, we require a mechanism to load the data into a central repository. The main reason for that is the business tools required to constantly store data in the underlying storage. Therefore, frequent connections to the source systems can put our production systems at risk of being unresponsive or performing poorly. The central repository where we store the data from various data sources is called Staging. We usually store the data in the staging with no or minor changes compared to the data in the data sources. Therefore, the quality of the data stored in the staging is usually low and requires cleansing in the subsequent phases of the data journey. In many BI solutions, we use Staging as a temporary environment, so we delete the Staging data regularly after it is successfully transferred to the next stage, the data warehouse or data marts.

If we want to indicate the data quality with colours, it is fair to say the data quality in staging is Bronze.

Data Warehouse/Data Mart(s)

As mentioned before, the data in the staging is not in its best shape and format. Multiple data sources disparately generate the data. So, analysing the data and creating reports on top of the data in staging would be challenging, time-consuming and expensive. So we require to find out the links between the data sources, cleanse, reshape and transform the data and make it more optimised for data analysis and reporting activities. We store the current and historical data in a data warehouse. So it is pretty normal to have hundreds of millions or even billions of rows of data over a long period. Depending on the overall architecture, the data warehouse might contain encapsulated business-specific data in a data mart or a collection of data marts. In data warehousing, we use different modelling approaches such as Star Schema. As mentioned earlier, one of the primary purposes of having a data warehouse is to keep the history of the data. This is a massive benefit of having a data warehouse, but this strength comes with a cost. As the volume of the data in the data warehouse grows, it makes it more expensive to analyse the data. The data quality in the data warehouse or data marts is Silver.

Extract, Transfrom and Load (ETL)

In the previous sections, we mentioned that we integrate the data from the data sources in the staging area, then we cleanse, reshape and transform the data and load it into a data warehouse. To do so, we follow a process called Extract, Transform and Load or, in short, ETL. As you can imagine, the ETL processes are usually pretty complex and expensive, but they are an essential part of every BI solution.

Continue reading “Business Intelligence Components and How They Relate to Power BI”

Power BI 101, Report Authoring Tools

This is my last blog post in 2021. I wish you all a wonderful break and a happy new year.

In the first post of my Power BI 101 series, we learnt that Power BI is a data platform containing various tools and services. We also explained the currently available subscriptions within the Power BI platform. The focus of the second post of this series is on what we should learn to achieve our goals more efficiently. In this post, we focus on the reporting tools available to us according to our subscription plan. From this post onwards, we discuss more specific aspects of the Power BI platform.

We learnt so far that Power BI is not just a reporting tool to build sophisticated reports; it is indeed a platform supplying a wide range of features from data preparation, data modelling and data visualization to contribute to an organisation’s data analysis journey in many ways such as sharing datasets, reports, and dashboards. All of these are possible only if we take the correct steps in building our Power BI ecosystem. But, it is very true that Power BI gives us the flexibility to create professional-looking and eye-catching visualisations providing easy to understand insights around a subject. The most renowned tool within Power BI is Power BI Desktop, but it is not the only tool available to us to create reports. Besides, Power BI Desktop reports are not necessarily the best answer to all business requirements. In fact, the business requirements define the Power BI architecture that supports those requirements. Based on the architecture, organisations decide to acquire a certain subscription plan, and based on the subscription plan, we have various reporting tools available to us. At this point, you might ask, “well, what architecture supports my organisation requires?”. Let’s answer that question in a future blog post.

For the purpose of this blog post, it is enough to know what reporting tools are available under which subscription plans. Let’s get started.

Reporting tools available in Power BI

As mentioned earlier, there are various reporting tools available to us. Let’s first see what reporting tools are available to us regardless of the subscription plans. Then we will look at the subscription plans supporting those tools.

Power BI Service

Power BI Service is a SaaS (Software as a Service) offering from Microsoft in the cloud. The users within an organisation, depending on their access rights, may create reports directly in Power BI Service. The users can also securely share and distribute those reports. While creating or editing reports is possible in Power BI Service, it is strongly recommended to avoid this method for several reasons. The most obvious one is that the changes we make to a report may soon get overwritten by someone else that republishes the same report from Power BI Desktop. Check this blog post from SQLChick to see why you should avoid creating or editing reports directly from Power BI Service. The reports are downloadable in PBIX format.

You can access Power BI Service here.

Power BI Desktop

It is a desktop application built for data preparation, data modelling and data visualisation. If you like to learn about data modelling with Power BI, check out my book here. We can use Power BI Desktop to connect to more than 250 different data sources, preparing, transforming and cleansing that data and at lastly visualising the data. Power BI Desktop is the predominant and most renowned report authoring tool available in the Power BI platform. It has many more functionalities and is more flexible than Power BI Service. For instance, setting up Role Level Security (RLS) is not available in Power BI Service. The file format of the reports created in Power BI Desktop is PBIX.

Download Power BI Desktop from here.

Power BI Report Builder (Paginated)

Paginated reports aka pixel-perfect reports are formatted in a way to fit perfectly on a page. That report page might later be printed. We have exact control over page formatting to display our data in tables or charts. The reports are not as interactive as the reports created in Power BI Desktop.

Paginated reports are based on RDL technology which is standard report format in SQL Server Reporting Services (SSRS). The tool for developing a paginated report in the Power BI ecosystem is Power BI Report Builder. The reports file type is RDL. We can currently publish Paginated reports only to a Workspace that is backed with either a Premium Per User (PPU) or a Premium Capacity.

Download Power BI Report Builder from here.

Power BI Desktop Optimised for Report Server (RS)

Power BI Report Server (PBIRS) is an on-premises server capable of rendering Power BI report files (PBIX). If we have a PBIRS up and running within our organisation and we require to publish Power BI reports to PBIRS, then we will need to create our reports in a special edition of Power BI Desktop which is optimised for PBIRS. This edition is different from Power BI Desktop, which we usually use to create and publish our reports to Power BI Service. For instance, Power BI Desktop RS does not include the preview features we used to see in Power BI Desktop until those features are released. Building reports in Power BI Desktop RS guarantees that the reports are fully functional after being deployed to our PBIRS. We can install Power BI Desktop and Power BI Desktop RS side-by-side on the same machine.

Download Power BI Desktop RS from here.

Continue reading “Power BI 101, Report Authoring Tools”
