Highlighting Below Avg Sales per Hierarchy Level with SWITCH() and ISINSCOPE() DAX Functions in Power BI

Highlighting Below Avg Sales per Hierarchy Level with SWITCH() and ISINSCOPE() DAX Functions in Power BI

I was working on a project a wee bit ago that the customer had conditional formatting requirement on a Column Chart.
They wanted to format the columns in the chart conditionally based on the average value based on the level of hierarchy you are at.
Here is the scenario, I have a Calendar hierarchy as below:

  • Calendar Hierarchy:
    • Year
    • Semester
    • Quarter
    • Month
    • Day

I use “Adventure Works DW2017, Internet Sales” Excel as my source in Power BI Desktop. If I want to visualise “Total Sales” over the above “Calendar Hierarchy” I get something like this:

Line Chart in Power BI, Total Sales by Year

Now I activate “Average Line” from “Analytics” tab of the Line chart.

Adding Average Line to Line Chart in Power BI

When I drill down in the line chart the Average line shows the average of that particular hierarchy level that I am in. This is quite cool that I get the average base on the level that I’m in code free.

Power BI, Drilling Donw in Line Chart

Easy, right?

Now, the requirement is to show the above behaviour in a “Column Chart” (yes! visualising time series with column chart, that’s what the customer wants) and highlight the columns with values below average amount in Orange and leave the rest in default theme colour.

So, I need to create Measures to conditionally format the column chart. I also need to add a bit of intelligent in the measures to:

  • Detect which hierarchy level I am in
  • Calculate the average of sales for that particular hierarchy level
  • Change the colour of the columns that are below the average amount

Let’s get it done!

Detecting Hierarchy Level with ISINSCOPE() DAX Function

Microsoft introduced ISINSCOPE() DAX function in the November 2018 release of Power BI Desktop. Soon after the announcement “Kasper de Jonge” wrote a concise blogpost about it.

So I try to keep it as simple as possible. Here is how is works, the ISINSCOPE() function returns “True” when a specified column is in a level of a hierarchy. As stated earlier, we have a “Calendar Hierarchy” including the following 5 levels:

  • Year
  • Semester
  • Quarter
  • Month
  • Day

So, to determine if we are in each of the above hierarchy levels we just need to create DAX measures like below:

ISINSCOPE Year		=	ISINSCOPE('Date'[Year])
ISINSCOPE Semester	=	ISINSCOPE('Date'[Semester])
ISINSCOPE Quarter	=	ISINSCOPE('Date'[Quarter])
ISINSCOPE Month		=	ISINSCOPE('Date'[Month])
ISINSCOPE Day		=	ISINSCOPE('Date'[Day])

Now let’s do an easy experiment.

  • Put a Matrix on the canvas
  • Put the “Calendar Hierarchy” to “Rows”
  • Put the above measures in “Values”
Detecting Year, Semester, Quarter, Month and Day hierarchy levels with ISINSCOPE in Power BI Desktop

As you see the “ISINSCOPE Year” shows “True” for the “Year” level. Let’s expand to the to the next level and see how the other measures work:

Continue reading “Highlighting Below Avg Sales per Hierarchy Level with SWITCH() and ISINSCOPE() DAX Functions in Power BI”

Quick Tips: How to Copy Visual Formatting to Multiple Other Visuals in One Go Using Format Painter Tool in Power BI

Format Painter in Power BI Desktop

When you create a report it’s highly likely that you’d like to copy other visuals’ formats from an already formatted visual using “Format Painter” tool in Power BI. Perhaps you already used this awesome tool available in Power BI Desktop.

As you see in the tooltip shown while hovering over the “Format Painter” tool you can simply copy formats from an already formatted visual to another visual. But what if you have a lot of similar visuals to be formatted (painted) like shown in the below screenshot that I have several card visuals on top of my page. One of them is formatted as desired but the rest must still be formatted.

Formatted/Unformatted Card Visuals in Power BI
Formatted/Unformatted Card Visuals

It would be good if I could paint all of them in one go right? So continue reading to see how we can do that.

Continue reading “Quick Tips: How to Copy Visual Formatting to Multiple Other Visuals in One Go Using Format Painter Tool in Power BI”

Quick Tips: How to Sort Matrix by Column in Descending Order

How to Sort Matrix by Column in Descending Order

Today Microsoft released Power BI Desktop March 2020 which I was hoping that it includes a simple feature on Matrix visual to be able to sort the Martix by column in descending order, but, it doesn’t. So, in this post I quickly show you how to sort Matrix by column in descending order.

Here is the scenario. One of my customers is building a report in Power BI showing sales by Year, Month and Day of Week in a Matrix as below.

Sorting Matrix Visual in Power BI
Sorting Matrix Visual in Power BI

Everything looks fine! But looking at the Matrix sorting quickly reveals that such feature is NOT available (YET). But the customer would like to see the Matrix sorted by Year in descending order, something like this.

Sorting Matrix by Column Headers in Descending Order
Sorting Matrix by Column Headers in Descending Order

Here is the solution which is super simple.

Continue reading “Quick Tips: How to Sort Matrix by Column in Descending Order”

Empower Your Story Telling Data Visualisation in Power BI with Colour Coding

Colour Coding in Power BI

This post has been waiting in my blogging list for a while and now this is my last post in 2019. I wish you all have a wonderful year ahead.

In this post I discuss a very important aspect of data visualisation; Colour Coding. I believe, colour coding is one the most powerful and efficient ways to provide proper information to the users. We learnt as human being that the colour can tell a lot about things. For instance, we look at green grass, if it is light green we immediately understand that the grass is quite fresh and healthy. When she gets a bit yellowish, we know that she’s perhaps thirsty. When it gets brown it is probably too late.

Another perfect example is traffic lights. When it is green, everyone is happy, when it is yellow, everyone is racing to pass the junction, well, I’m just kidding, some people tend to pass the yellow light while everyone knows they have to stop when traffic light is yellow right?? And… when it is red, we have to stop. Enough saying about colour coding and its affects on our lives on a day to day basis. Let’s talk about colour coding in Power BI and quickly get to more exciting stuff.

So… colour coding in Power BI, well, we could colour code from the day first that Power BI born, but, perhaps not in a way that I’m going to explain in this post. Conditional formatting is also around for a while now. In this post I show a technique that we can implement in Power BI to use a consistent colour coding across the whole report.

Here is a report without colour coding:

  Power BI Report without Colour Coding
Power BI Report without Colour Coding

And now look the same report that is colour coded:

 Colour Coded Power BI Report
Colour Coded Power BI Report

Let’s get into it.

Getting Started

In this technique we’ll follow the steps below:

  • We jump online using some awesome free colour palette websites to generate the colours we’d like to use in our reports
  • We copy the HEX values and paste into Power BI (via Enter Data)
  • We define a range of numbers to identify the ranges that our values will fall into. I personally use percentage, but it might be something else in your case
  • We then define some measures to pick a specific colour for the measures we want to colour code
Continue reading “Empower Your Story Telling Data Visualisation in Power BI with Colour Coding”

Quick Tips: Line Chart and Area Chart Conditional Formatting in Power BI

Line Chart and Area Chart Conditional Formatting in Power BI

In this post I show you a very quick trick to format Line Chart and Area Chart conditionally in Power BI. As this is a “Quick Tip” I’m going to keep this post really short.

One of my customers asked me to show time series in line charts and area charts. But she want’s it to be conditionally formatted based on the average value over time. Let’s keep it simple, she wants to show “Sales by Year Month” in line chart, but, highlight the data points that are below “Average Sales per Year Month”. As you may know, we currently do not have the luxury of formatting line charts and area charts. But wait, this post is all about that. Let’s dig into it.

From the above scenario, you perhaps already guessed that we need to create a measure which defines the colour based on “Average Sales per Year Month” to be able to format the chart conditionally. If any data point is below the “Average Sales per Year Month” then we highlight it in Orange, if it is above the “Average Sales per Year Month” then we stick to the default colour.

Let’s do it.

Continue reading “Quick Tips: Line Chart and Area Chart Conditional Formatting in Power BI”

Good Practice: Always Display the Reporting Environment

Good Practice: Always Display the Reporting Environment

When you work on real-world projects in power BI, you would probably have different environments Like DEV, UAT, Pre-Prod and Prod. It is important for you and your audience to know what the data is coming from. Am I looking at Dev or UAT data or I am actually looking at real data in Production environment. You may have asked or been asked with a question like “Where the data is coming from?”. It is important to know how trustworthy the data you’re analysing is. In this post I show you an easy way to show the environment your Power BI report is connected to.

How It Works

To display the environment name you use query parameters, then you reference that parameter, turn it to a table and add columns to show the environments accordingly. Easy right?

Read more about query parameters from a list output here.

Depending on your scenario the implementation might be slightly different, but the principals are the same. In this post I use a SQL server database. Therefore I need to Parameterise server name. in real world you may also need to parameterise the database name. Again, if your case is quite different, like if you get data from Excel, then the Excel path can be different for different environments. Let’s dig-in.

  • Open Query Editor
  • Click “Manage Parameters”
  • Click “New”
    • Enter “Name” and “description”
    • Tick “Required”
    • Select “Text” in “Type”
    • Select “List of values” in “Suggested Values” and type in server names for different environments
    • pick a “Default Value” and “Current Value”
    • Click OK
Creating new parameter in Power BI Query Editor

So far you created a new parameter that can be used to get data from a SQL Server data source.The next steps show you how to use that parameter to show the environments in your reports.

Continue reading “Good Practice: Always Display the Reporting Environment”
